Fish Passage Site 20703259

Coordinates (dec. deg.): 57.76954°, -152.54372°
Legal Description: S028S020W09
Region: Southwest
Road Name: Magazine Access Road

Datum: NAD83
Quad Name / ITM: Kodiak D-2
AWC Stream #:
Stream Name: Unnamed

Elevation:

Site Comments: Culvert is located on an access road for two decommissioned artillery magazines. ADF&G has recommend this road be closed and this culvert be removed.

Survey Date: Oct 24, 2013

Survey UPDATE-KOD10

Project Supervisor: Gillian O'Doherty, ADFG
Observers: William Frost

Overall Fish Passage Rating: Blue

Tidal: No
Backwatered: No

Step Pools: No
Construction Year:


Site Observations:

  1. Compound gradient in pipe
  2. Mechanical damage or joints parting
  3. Structural Problem

Comments: Site submitted by ADFG HB Will Frost. Additional site photos submitted by Heather Hanson USFWS from April 2016 site visit.. Not Fish Bearing.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated steel) Fish Passage Rating: Black

Length(ft):
Inlet Type: Projecting
Outlet Type: Projecting
Corrugation Depth(in.):
Corrugation Width(in.):
Condition Rating(1-5): 1
Approach Angle:
Sedimentation At Inlet: Unknown
Inlet Substrate:
Outlet Substrate:
InletOutlet
Width(ft):
Height(ft):
Apron Length(ft):
Water Depth(ft):
Rustline Height(ft):
Substrate Depth(ft):
Backwatered?: No
Baffles Present: No
Embedded?:
Outfall Height:
Outfall Type: Free Fall In To Pool
Constriction Ratio:
Culvert Gradient:
Max Slope:
Max Slope Length:


Comments: Culvert outlet is damaged and creates a large compound gradient at the end of the pipe. Culvert diameter estimated at about 2 feet.
  Culvert Observations:
  1. Compound gradient in pipe
  2. Mechanical damage or joints parting
  3. Structural Problem

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):
Stream Flow Stage:High

No stream width data available.

Elevations

No elevation data available.

Fish Sampling Efforts

No fish sampling occurred during this survey.

Fish Observations

No fish observations occurred during this survey.
