Fish Passage Site 20203732

Coordinates (dec. deg.): 60.12098°, -149.43985°
Legal Description: S001S001W03
Region: South Central
Road Name: Port Avenue

Datum: NAD83
Quad Name / ITM: Seward A-7
AWC Stream #: 231-30-10070-2016
Stream Name: Unnamed

Elevation:

Site Comments: None

Survey Date: Jul 13, 2017

Survey KEN17-48_2006

Observers: Jeff Sires, Luke Violette, Louis Mitchell

Overall Fish Passage Rating: Red

Tidal: No
Backwatered: No

Step Pools: No
Construction Year:


Site Observations:

  1. Constriction ratio red
  2. Culvert gradient red
  3. Woody Debris
  4. Culvert is poorly aligned
  5. Culvert sagging in middle

Comments: KWFRES_17_03 Site assessment information and photos collected and submitted by the Kenai Watershed Forum. Upstream and downstream have been ditched. Upstream channel runs along side railroad tracks for over a quarter mile before reaching source. Site is upstream from 49_2006 and a culvert that runs under the NAPA driveway. Sockeye and Dolly Varden Char caught upstream and downstream from site.

Culvert Measurements

ID: 1 Structure Type: Circular pipe (Corrugated steel) Fish Passage Rating: Red

Length(ft): 112.0
Inlet Type: Projecting
Outlet Type: Projecting
Corrugation Depth(in.): 0.5
Corrugation Width(in.): 2.5
Condition Rating(1-5): 2
Approach Angle: 46.0
Sedimentation At Inlet: No
Inlet Substrate: None
Outlet Substrate:
InletOutlet
Width(ft):2.0 1.9
Height(ft):2.0 1.4
Apron Length(ft):
Water Depth(ft): 1.29
Rustline Height(ft):0.9
Substrate Depth(ft):0.0 0.6
Backwatered?: No
Baffles Present: No
Embedded?: No
Outfall Height: 0.0
Outfall Type: At Stream Grade
Constriction Ratio: 0.42
Culvert Gradient: 1.46%
Max Slope:
Max Slope Length:


Comments: Outlet is fully submerged.
  Culvert Observations:
  1. Constriction ratio red
  2. Culvert gradient red
  3. Culvert is poorly aligned
  4. Culvert sagging in middle
  5. Woody Debris

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):1.16
Stream Flow Stage:Medium
Stream Width Type Distance From
Crossing (ft)		 Stream
Width (ft)
Upstream ordinary high water 12.0 4.12
Upstream ordinary high water 35.0 3.50
Upstream ordinary high water 55.0 5.86
Upstream ordinary high water 75.0 5.75

Elevations

Locator ID Culvert
Number		 River
Distance (ft)1		 Distance From
Crossing (ft)2		 Relative
Elevation (ft)
Road Elev 95.32
D/S Thalweg 0.00 90.95
D/S Water Surface Elev 0.00 91.54
D/S Grade Ctrl (Thalweg) 28.00 91.45
D/S Water Surface Elev 28.00 91.88
D/S Water Surface Elev 48.00 92.06
D/S Grade Ctrl (Thalweg) 48.00 91.85
D/S Thalweg 95.00 91.61
D/S Water Surface Elev 95.00 92.16
D/S Water Surface Elev 100.00 92.16
Outlet Invert (on substrate) 100.00 90.87
Outlet Culvert Top 100.00 92.10
Inlet Culvert Top 212.00 93.74
Inlet Culvert Invert (on pipe) 212.00 91.80
U/S Water Surface Elev 212.00 92.17
U/S Water Surface Elev 219.00 92.52
U/S Grade Ctrl (Thalweg) 219.00 92.07
U/S Water Surface Elev (stream gradient) 222.00 92.68
U/S Thalweg 222.00 92.30
U/S Grade Ctrl (Thalweg) 239.00 93.05
U/S Water Surface Elev 239.00 93.28
U/S Water Surface Elev 255.00 93.69
U/S Grade Ctrl (Thalweg) 255.00 93.70
U/S Thalweg 282.00 93.36
U/S Water Surface Elev 282.00 93.66
U/S Water Surface Elev (stream gradient) 312.00 93.72
U/S Thalweg 312.00 93.31

Notes:

  1. River distance is measured continuously throughout the survey reach along the thalweg of the stream.
  2. Measured from each end of the crossing along the thalweg of the stream.

Fish Sampling Efforts

Gear Type: Minnow Trap (A) Trap Duration(h): 2.0
Comments: Trap set about 120 feet downstream

Gear Type: Minnow Trap (B) Trap Duration(h): 2.1
Comments: Trap set about 50 feet upstream

Fish Observations

Species: juvenile sockeye salmon Life History: Anadromous
Total Fish Observed: 2 Fish Measured: 2 Fork Lengths (mm) Min: 40 Max: 45 Mean: 42
Collected/Observed by Gear Type: Upstream Minnow Trap (1)  Downstream Minnow Trap (1)

Species: juvenile Dolly Varden Life History: Unknown
Total Fish Observed: 2 Fish Measured: 2 Fork Lengths (mm) Min: 90 Max: 110 Mean: 100
Collected/Observed by Gear Type: Upstream Minnow Trap (1)  Downstream Minnow Trap (1)
