Fish Passage Site 10302242

Coordinates (dec. deg.): 58.43782°, -135.66740°
Legal Description: C040S059E04
Region: Southeast
Road Name: Wilson Road, Berry Creek Drive

Datum: NAD83
Quad Name / ITM: Juneau B-5
AWC Stream #:
Stream Name: Rink Creek tributary

Elevation:

Site Comments: Wilson Road, Berry Creek Drive.

Multiple surveys have been conducted at this site — click on the drop down
arrow to the right of the survey date below to choose a different report for this site.

Survey UPDATE-WBD01

Project Supervisor: Gillian O'Doherty, ADFG
Observers:

Overall Fish Passage Rating: Green

Tidal:
Backwatered: Unknown

Step Pools:
Construction Year: 2012


Site Observations:

  1. None of this type

Comments: Replaced in April 2012. All information provided by USFWS. This site has not been resurveyed by ADF&G.

Culvert Measurements

ID: 1 Structure Type: Pipe-arch (Corrugated steel) Fish Passage Rating: Green

Length(ft):
Inlet Type: Projecting
Outlet Type: Projecting
Corrugation Depth(in.): 1.0
Corrugation Width(in.):
Condition Rating(1-5): 5
Approach Angle:
Sedimentation At Inlet: Unknown
Inlet Substrate:
Outlet Substrate:
InletOutlet
Width(ft):
Height(ft):
Apron Length(ft):
Water Depth(ft):
Rustline Height(ft):
Substrate Depth(ft):
Backwatered?: Unknown
Baffles Present: No
Embedded?: Yes
Outfall Height: 0.0
Outfall Type: At Stream Grade
Constriction Ratio:
Culvert Gradient:
Max Slope:
Max Slope Length:


Comments: Measurements taken from site plans and have not been verified by project personell. Culvert width 7.5 ft. Culvert height 5.25 ft. Substrate depth 1.5 ft. Culvert length 33 ft. Culvert slope 0.5%.

  Culvert Observations:
  1. None of this type

Stream Measurements

Stream SubstratesUpstreamDownstream
Dominant:
Subdominant:
Stream Slope(deg.):
Stream Flow Stage:Low

No stream width data available.

Elevations

No elevation data available.

Fish Sampling Efforts

No fish sampling occurred during this survey.

Fish Observations

No fish observations occurred during this survey.
